ABOUT

Polykod company specializes in software developing for the oil-gas industry and educational and academic organizations.

The software platform is web applications based on a client-server architecture with a high degree of reactivity between clients and with dedicated servers: authorization server, client interface server, application logic server, mathematical operations server and database server.

This allows you to achieve a high degree of flexibility and security at the same time, which is especially important when working together on projects from different places. In particular, Polycode applications are available to users from any operating platform.

The company's applications implement the concept of SAAS (Software-As-A-Service), which can be run in the cloud (Cloud version) or in a closed corporate network (Box version).

PRODUCTS

PolyGon software is a comprehensive tool for analyzing and interpreting dynamic flow rate and pressure data into the oil and gas field development process. The software includes modules for initial development analysis (displacement curve analysis, productivity analysis, reservoir development maps), PVT fluid models, SCAL reservoir models, reservoir pressure interpretation, PTA and single-well deconvolution, classical and pressure pulse-code testing, multi-well deconvolution, CRM- models and numerical 2D + modeling.

PolyPlan software is the Oil and Gas Synthetic model simulating a reservoir-well-infrastructure system taking into account the economics and logistics of supply and the ability to simulate well and reservoir studies. PolyPlan software is used to design development of new assets, monitor deviations in current assets and as a simulator for training in analysis and field development.

photo #1

The Purpose

PolyGon is a software tool for interpretation of:

  • wellbore pressure response to the flow rate variation in the same well or offset wells
  • production rate and formation pressure response to the bottom hole pressure variation in the same well or offset wells
  • multiwell system
photo #1

Operating Platform

PolyGon is implemented as web-application and can be accessed through local office network or Internet connection from the majority of computer devices and OS, supporting popular web-browsers.

photo #1

Remote Server

The application components are carefully balanced between the user device and remote server, installed on a powerful multicore workstation where most of the processing, modeling, recognition and fitting work is performed. This allows users to access their personal data in secure format from anywhere in the world and run heavy-duty data processing with slim devices, including the tablets.

photo #1

PolyGon Data Security

The user data is stored in encoded format and secured against fails through the cloud mirroring. The connecon between Client devise and remote server is using secured protocols and data encoding

photo #1

PolyGon Data Centers

Users can select PolyGon Server from several Data Centers across the world depending on their proximity and customize computational power of PolyGon Server based on the processing needs.

photo #1

User Interface

The Wizard-type interface provides intuitive connection with users.

photo #1

Fluid Properties

PolyGon supports wide range of Black-Oil and water correlations for: Density, Formation Volume Factor, Gas/Oil Rao, Bubble Point pressure, Viscosity, Heat Capacity, Thermal Conductivity.

  • provides non-linear fitting facility to extend the application of BO correlations * provides global fitting of all fluid samples and all fluid properties with a button click * supports non-isothermal modelling
photo #1

Relative Permeabilities

PolyGon supports 3-phase relative permeabilities based on Stone I, Stone II and Baker models and Correy functions for 2-phase relative permeabilities.

photo #1

Well Sketch

PolyGon supports wide variety of well designs to simulate the pressure responses at the actual location of the gauge using popular multi-phase flow correlations and actual well trajectory. Pump model includes the switch between constant rate and constant boom hole pressure regimes.

photo #1

Map Facility

PolyGon provides facility to build a 2D model for each layer, including the formation top, thickness, permeability, porosity, formation compressibility, fluid saturation, wells locations and trajectories, faults and boundaries.

photo #1

Detrending

PolyGon implements advanced methods of detrending of pressure and rate variation based on the correlation with production history which is a key element of multi-well pressure interference analysis.

photo #1

Pressure Pulse-Code Test

PolyGon provides interpretation facility for pressure interference test featuring a fitting facility for pressure response to the rate variation in the offset well. This facility includes a powerful detrending mechanism which can recognize the response to flow rate variation of a given well and exclude the influence of the other wells.

photo #1

Multi-well Deconvolution

PolyGon provides the deconvolution facility to reconstruct the long-term unit-rate pressure response from the long-term pressure-rate history. There are several popular options, including the Shroeter and Levitan methodologies.

photo #1

Diffusion Models

PolyGon supports a wide variety of diffusion models:

  • Wellbore Storage: constant, variable
  • Well: vertical, limited entry, slanted, fractured, horizontal
  • Reservoir: homogeneous, dual porosity, dual layer, radial composite, linear composite
  • Boundaries: Infinite, closed, faults

Mulphase diffusion is covered by linear 3-phase Perrine and more advanced non-linear 3phase pseudo-pressure/pseudo-me approach.

photo #1

Slope-based Analysis

Conventional slope-based analysis provides manual assessment of basic diffusion parameters:

  • wellbore storage
  • skin factor
  • permeability
  • boundary type
  • distance to a boundary
photo #1

Mul-Rate Step-Response

PolyGon provides interpretation facility for multi-rate step-response test which is normally used when shutting down the well is not technically or economically viable (flow noise response).

photo #1

Video-training Facility

The built-in context video-training facility provides a detailed insight into the data input, processing procedure and interpretation.

KEY FEATURES

KEY FEATURES

POLYGON SOFTWARE USING FOR PRESSURE AND PRODUCTION RATE INTERPRETATION FOR DETERMINING RESERVOIR CHARACTERISTICS

KEY FEATURES

INTERPRETATION CAN BE CARRIED OUT SIMULTANEOUSLY IN MORE THAN TWO WELLS

POLYGON FEATURES FOR MULTIWELL INTERPRETATION:
  • 1
    2D+ piezosimulator (high speed calculations of numerical models)
  • 2
    Pulse-Code Detrending (selection of true signal from a generator at receivers)
  • 3
    A unique method of filtering pressure data from different types of noise
  • 4
    The multi-well deconvolution algorithm (taking into account the influence of neighboring wells (their flow rates and injectivity) and determining more accurate reservoir characteristics)
  • 5
    Unique fitting method (pressure auto-adaptation for all wells simultaneously)
